China 300W Waterproof constant current LED driver, LED switching power supply factory and manufacturers

300W Waterproof constant current LED driver, LED switching power supply

Short Description:

Overview Quick Details Place of Origin: Guangdong, China Brand Name: ILM Model Number: ILM-LCC033 Output Power: 201 – 300W Output Type: Single Input Voltage: 90-250VAC Output Frequency: 50/60HZ ...

Send email to us Download as PDF

Product Detail

Product Tags

Overview

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: ILM

Model Number:: ILM-LCC033

Output Power:: 201 – 300W

Output Type:: Single

Input Voltage:: 90-250VAC

Output Frequency:: 50/60HZ

Output Current:: 5A-30A

waterproof LED driver:: 300W

constant current LED driver:: 5A-30A

IP67 LED driver:: 300W

Output Voltage:: 12~85VDC

1. Universal AV input with full range: 100VAC~250VAC

2.Built-in active PFC fuction, PFC≥0.95

3.Comply with IP67, EMC standard

4.Fully encapsulated aluminum housing, suitable for wet, dry, damp locations

5.Protection: Over voltage, Over load, Over temperature, Short circuit

6.High efficiency (87%~88%)

7.Compliant to worldwide safety regulations for lighting

8.Long life span: 50000hrs

9.100% burn-in tests (at full load), full-round tests.

10. 3 years warranty

11. Rated output can be customized

Model	ILMLCC-300
DC Current	5A-30A
DC Voltage	12~85VDC
Rated Power	300W
Input Voltage	90~130VAC / 170~250VAC / 100~250VAC
Over Voltage Protection	130%
Over Power Protection	130%
Active PFC	0.95
EMC	EN55015: 2007 / EN61547: 1995+A1: 2000 / EN61000-3-2, EN61000-3-3: 2008
Efficiency	89%
Life Span	68000hrs
MTBF	250Khrs
Withstand Voltage	I/P-O/P: 3KVAC, IP-FG:1.5KVAC, DC-FG: 500VAC
Working Temperature	-35~+70°C
Size	2369553mm
Packing	2.6Kg/pcs, 15pcs/CTN

.Suitable for LED electronic display screen, LED street lights, LED tunnel lights, LED bridge lights, LED panel lights, LED ceiling lights, moving sign application, etc
